Engine Type: SOHC 4-stroke Displacement: 686cc Bore x Stroke: 102.0mm x 84.0mm Engine Cooling: Liquid Fuel System: Yamaha Fuel Injection (YFI), 44mm Front Suspension: Independent double wishbone; 5-way preload adjustment Front Travel: 7.6 in. Front Brake Type: Dual hydraulic disc Front Tires: AT26 x 8-12 Maxxis® MU05Y Rear Suspension: Independent double wishbone with anti-sway bar; 5-way preload adjustment Rear Travel: 9.1 in. Rear Brake Type: Dual hydraulic disc Rear Tires: AT26 x 10-12 Maxxis® MU06Y Dry Weight: Curb Weight: 701 lb. Front Rack Capacity: 110 lb. Rear Rack Capacity: 198 lb. Towing Capacity: 1322 lb. Fuel Capacity: 4.8 gal. Ground Clearance: 11.3 in. Machine Dimensions (LxWxH): 81.5 in. x 48.4 in. x 49.3 in. Wheelbase: 49.2 in. Final Drive: On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft Transmission: Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P Colors: Realtree Edge w/Aluminum Wheels
